8 Axis Single Head Ball Faceting Machine

Model No : OM-8BL-APNP-SH

Specification	Details
Number of Milling Head	Horizontal With 360 degree
Type of Main Centre	Universal
Number of Axis	8 Axis T – Rotating of Jobs A –Tilting B – Rotating Horizontal holder (360 Degree) X – Longitude for Centering Jobs Z – Cutting Depth for Jobs C – Horizontal Tool Servo For Synchronal Operation X1 – Place Ball Z1– Pick Ball
Type of Jobs	Round Ball (2 mm To 6 mm) Ovel Ball Pipe Length 4 to 12mm
Operating	Touch Screen HMI
Main Features	Auto Rejects Defects & Uneven Balls , Measuring Live Ball Size.
Milling Speed	Horizontal – 10000 rpm (max)
Milling Spindle Motor	Horizontal – 400 w
Dimension With Cabinet	L x W x H = 40 x 30 x 68 (inches)
Machine Weight	450 kg
